Slubbing Frame
Howard and Bullough Limited
Category
Machinery and industrial devices
Date
1926
Materials
Metal
Measurements
189 cm (height)484 cm (length)85 cm (width)
Place of origin
Accrington
Order this imageCollection
Quarry Bank, Cheshire
NT 1453852
Summary
A slubbing frame made by Howard and Bullough Ltd, Accrington, in 1926, and rebuilt by Dodds in 1950. This is the third machine to process the raw cotton. The machine takes the cans of drawn cotton slivers (strands) from the back through a set of drafting rollers, making the sliver finer, and adds in a slight twist for strength with the fly arms. The carriage at the front travels up and down to wind the cotton roving (thin strands) down onto a bobbin, and when full the bobbin is doffed (removed) from the machine.
Provenance
This slubbing frame was a gift from Mutual Mills in Heywood, Lancashire.
Marks and inscriptions
Ends of machine: Howard and Bullough Ltd Accrington Ends of machine: Howard and Bullough Ltd Accrington End: S. Dodd and Sons Ltd Oldham England 1950 ref no. 29/7/11 Ends of machine: Howard and Bullough Ltd Accrington End: S. Dodd and Sons Ltd Oldham England 1950 ref no. 29/7/11 End: triangular; A Dodd Rebuilt Machine Ends of machine: Howard and Bullough Ltd Accrington End: S. Dodd and Sons Ltd Oldham England 1950 ref no. 29/7/11 End: triangular; A Dodd Rebuilt Machine By weights underside rear of machine: 10 Ends of machine: Howard and Bullough Ltd Accrington End: S. Dodd and Sons Ltd Oldham England 1950 ref no. 29/7/11 End: triangular; A Dodd Rebuilt Machine By weights underside rear of machine: 10 Inside edge of the end of the machine: R10 Ends of machine: Howard and Bullough Ltd Accrington End: S. Dodd and Sons Ltd Oldham England 1950 ref no. 29/7/11 End: triangular; A Dodd Rebuilt Machine By weights underside rear of machine: 10 Inside edge of the end of the machine: R10 On the motor at the top of the end of the machine: Brook Motors Ltd. Huddersfield
Makers and roles
Howard and Bullough Limited, manufacturer
