Survey plan of the first floor of Wimpole Hall, Cambridgeshire
George Philip Banyard (1880 - 1948)
Category
Architecture / Drawings
Date
Feb 1940 - Mar 1940
Materials
Pen and ink
Measurements
600 x 1100 mm
Place of origin
Cambridge
Order this imageCollection
Wimpole, Cambridgeshire
NT 206303.3
Summary
George Philip Banyard (1880-1948). Survey plan of the first floor of Wimpole Hall, Cambridgeshire, 1940, inscribed 'SURVEY OF WIMPOLE HALL, CAMBRIDGESHIRE'; 'FIRST FLOOR PLAN'; and 'Measured & Drawn by Geo. P. Banyard, FRIBA, Cambridge Feb. Mar. 1940', the room functions are marked, pen and ink (1100 x 600mm), scale 'EIGHT FEET TO ONE INCH', verso: a 'picture' [?plan] of the second floor. This plan shows that the kitchen in Kendall's east service wing was a double-height space.
Provenance
Bequeathed by Elsie Kipling, Mrs George Bambridge (1896 – 1976), daughter of Rudyard Kipling, to the National Trust together with Wimpole Hall, all its contents and an estate of 3000 acres
Marks and inscriptions
Above plan: SURVEY OF WHIMPOLE HALL, CAMBRIDGESHIRE Below plan: FIRST FLOOR PLAN Right hand side: Surveyed & Drawn by / Geo P. Banyard, FRIBA, / Cambridge / Feb. Mar. 1940 Bottom: EIGHT FEET TO ONE INCH [scale]
Makers and roles
George Philip Banyard (1880 - 1948), architect
References
Adshead 2007: David Adshead, Wimpole Architectural drawings and topographical views, The National Trust, 2007, p.136, no. 311
