Biform lens

Chance and Co.
National Trust Inventory Number 238453

Category Technological items
Date 1915
Materials Glass, iron and mercury
Measurements
Place of origin Smethwick
Collection Souter & the Leas, Tyne & Wear (Accredited Museum)
Not on show

Summary description

Biform optic or lens with a wide base turntable of metal, the catadioptric lens has three faces consisting of 1008 pieces of glass set in a metal frame. This is supported on an iron base with twelve guide wheels which keep the lens in place as it effortlessly rotates on a flotation tank of mercury, when in use the light turned at four revolutions per minute. Originally Souter was a white light, but in September 1919 it was changed to red, the filter is visible through gaps in the lens.

Makers and roles

Chance and Co., photographer
